Quick Details

  • Properties: Orthopedic Surgical Instruments
  • Type: Drill
  • Brand Name: Bojin
  • Model Number: System 4200
  • Place of Origin: Shanghai, China (Mainland)
  • Main material: Stainless steel, aluminium alloy
  • Application: For cutting,drilling, K wire, acetabulum reaming.
  • orthopedic system: Multifuction
  • battery voltage: 14.4v
  • battery: rechargeable
  • Feature: variable speed
  • advantage: lower noise
  • Packing: Aluminum Box,carton
  • Certificate: CE ISO FDA
  • Warranty: 2 years

Packaging & Delivery

Packaging Details Aluminum case.
Delivery Time Within 3 days after payment.

medical bone drill saw for orthopedic surgery BJ4200



Application:

Sagittal saw(BJ4201): For application in cutting bone during joint surgery.

With the perfect shape of ergonomic design,whole unit is autoclavable,motor is imported,low noise, steadily and quickly cutting,no damage for soft tissue,long service life,be warranty for 1 year.A variety of different thickness or the length of the saw blade for your selection .Common length are 70mm,90mm and 100mm,common thickness are 0.8mm,1.0mm,1.2mm and 1.27mm,saw blade also can be customized according to your request.

 Bone drill system 4200

Specification:

Output power

110W

Speed(r.p.m)

/

Oscillations (osc/min)

0-15000

Torque(Nm)

/

Operation(V) voltage

14.4

Sterilization

155°C

Swings (°)

/

Noise(db)

≤75



AO drill(BJ4202;BJ4202SAO):

For application in drilling hole for plate and screw during trauma surgery.

With the perfect shape of ergonomic design,whole unit is autoclavable,motor is imported,low noise,high speed,high proper alignment,long service life. The machine is warranty for 1 year. Can connect dedicated drill bit produced by our factory,drill bit changing during the process of surgery is more convenient and quick.



Specification:

Output power

110W

Speed(r.p.m)

0-1000

Oscillations (osc/min)

/

Torque(Nm)

3.2

Operation(V) voltage

14.4

Sterilization

155°C

Swings (°)

/

Noise(db)

≤40



Dual function acetabulum reaming drill(BJ4207B;BJ4207D):

For application in acetabulum reaming during joint surgery.

With the perfect shape of ergonomic design,whole unit is autoclavable,motor is imported,low noise,high torque, long service life. The machine is warranty for 1 years. Different interface can be customized according to different factory’s shaft and reamer, tool connecting is very convenient and quick,higher stability.



Specification:

Output power

≥85w

Speed(r.p.m)

0-320

Oscillations (osc/min)

/

Torque(Nm)

7.8

Operation(V) voltage

14.4

Sterilization

155°C

Swings (°)

/

Noise(db)

≤40



Advantage:

1.The main components are made of high-strength stainless steel.

2.High proper alignment, low noise.

3.155 autoclavable.



Attachments for your selection:

1.Sagittal saw

2.Bone drill, AO drill.

3.Dual function acetabulum reaming drill.



Standard Configuration:

1.One handpiece
2.Two battery
3.One charger
4.Three saw blade
5.One Aseptic battery transfer ring
6.One Operating manual
7.One Guarantee Card


Warranty:

The handpiece guarantees for 1 year, the battery and other fast consumption items guarantee for 3 months.



Advantages:

1.Our whole power tool can be autoclavable.

2.We can autoclavable for 135 °C (Improved type ≤ 155 °C ),with 1.6Mpa,in this way the bacilli and virus which can not killed bythe suffocating will be killed.

3.We use environment friendly nickel-metal hydride battery.

4.The machine has very low noise.

5.Our products has 1 year warranty period.



Notes:

1.Sterilize temperature ≤ 135 °C (Improved type ≤ 155 °C ),if the temperature is over 135 °C, the motor will be damaged.

2.Normal bone drill can only hold drill bits less than 6mm,acetabulum reaming drill with big torque,rpm is around 300,canulate drill is used with nail or K wire ,rpm is around 600.

3.The battery need to be get out of the power tool after surgery.Otherwise the small automatic discharge of the electric will make the life of the battery short.

4.The battery cannot be sterilized ,it is not autoclavable.

5.The cranial bur must be washed right after the surgery by purger in order to avoid the blood stick in the bur,then we should make it dry.

6.The battery space in the handpiece of the tool should not have any water,after sterilization.

7.The cranial bur blade is made of medical stainless steel,in order to avoid broken,so it is flexible and not very hard,it is easy to be attrite,we suggest each blade only use for 1 surgery.
